Bathymetry

Our systems utilize survey-grade echosounders paired with RTK GNSS positioning, delivering vertical accuracy of ±2.5cm in ideal conditions. Comparative studies between our drone-mounted systems and traditional boat-based surveys show negligible differences in collected data, confirming that aerial bathymetry maintains professional standards while offering significant operational advantages.

Our systems are ideal for surveying inland water bodies such as lakes, ponds, rivers, reservoirs, and tailings facilities, as well as coastal areas like harbors and shorelines. They excel in locations where traditional boat access is difficult, dangerous, or environmentally disruptive. The systems can collect data in water depths up to 200m, depending on the specific echosounder model.

The workflow maintains familiar elements while eliminating boat-related logistics. Survey planning is performed using UgCS software, with flight lines automatically generated based on your coverage and resolution requirements. During execution, the drone follows the predetermined path while the echosounder collects depth data and the SkyHub computer handles synchronization and data logging. Post-processing uses industry-standard software like Eye4Software Hydromagic, resulting in the same deliverables you'd expect from traditional methods.

Our echosounder systems integrate with professional drone platforms, including DJI M300/M350 RTK, DJI M400, Inspired Flight IF1200A/IF800, Harris Aerial H6, and Wispr Ranger Pro. The modular design allows for adaptation to various UAV platforms based on your specific requirements for flight time, payload capacity, and operational conditions.

We offer comprehensive training programs covering system setup, calibration, flight planning, data collection protocols, and basic data processing. Our support continues beyond training with technical assistance for field operations and data interpretation. Most professionals with basic drone experience can become proficient with our echosounder systems after completing our structured training program.
